SONY UP-D897
SONY UP-D897 Digital B/W Printer (A6)
- USB 2.0 High Speed Interface
- Ideal for digital ultrasound printing
- User friendly controls on front panel
- Fast print speed - approximately 2.0 seconds in high speed mode
- 3 Media Choices - UPP-110HG, UPP-110HD or UPP-110S/5
The Sony UP-D897 thermal printer is the ideal choice for digital ultrasound systems. This monochrome black and white printer incorporates a USB 2.0 interface for easy integration to digital ultrasound systems. The Sony UP-D897 printer packs a powerful set of features in a small package. Sony's smallest ultrasound printers ever, the UP-897 models measure only approximately 6 inches wide x 3 1⁄2 inches high x 9 1⁄2 inches deep.
Sony UPD897 Digital B/W Printer Specs
| Printing Method | Thermal Head |
| Thermal Head | Thin Film Thermal Head (1280 dots) |
| Gradations | True 256 gray balance |
| Resolution | 325 DPI |
| Printed Picture Size | 4"(W) x 12 5/8" (H) |
| Effective Pixels | Maximum 4096 x 1280 dots |
| Memory | 4096 x 1280 x 8 bit | Interface | USB 2.0 High Speed Interface |
| Print Speed | Approximately 2.0 seconds (High Speed Mode) |
| Power Requirements | 100V to 240V, 50/60 Hz, 1.5A to 0.8A (Worldwide) |
| Dimensions (WHD) | 6 1/8 x 3 1/2 x 9 1/2 inches 154mm x 88mm x 240mm |
| Weight | Approximately 5 lbs. 12oz. 2.6kg |
| Safety Standards | UL60950-1 Listed + CSA C22.2 No. 60950- 1 + UL60601-1 Listed + CSA No. 60601-1 |
| Supplied Accessories | AC Power Cord Operation Manual (CD ROM) Driver Software |
